afx light PARCOB100HEX Bedienungsanleitung Seite 6

Strobe
4 0-10 No function
11-255 Strobe with increasing speed
Built-in program
0-20 No function
21-30 Fixed program AT01
31-120 Fixed program AT02~AT10
7
121-130 Build-in program PR01
131-220 Build in program from PR02-PR10
221-240 Color change via sound
241-255 Flash effect via sound
Speed for built-in program
8
0-255 Speed from slow to fast
Dimmer Optional (1st channel Dimmer be open)
0-9 Dimmer speed
10-29 No function
9 30-69 Dimmer 1
70-129 Dimmer 2
130-189 Dimmer 3
190-255 Dimmer 4
ID selection (After select the fixture per ID1~ID66, control via DMX when open value as below per
each model even they are at same DMX value )
No function
10
0-9 Each 10 value with a ID from ID1 until ID19
10-211 Each value with a ID from ID20 until ID66
211-222
DMX protocol OF PARCOB100HEX
ARC.1 3 Channel mode
Channel
2
3
4
AR1.D 4 Channel mode
Channel
1
2
3
4
ARC.2 6 Channel mode
Channel
1
2
3
4
©Copyright Lotronic 2019
Value Function
0-255 Red: 0-100%
0-255 Green: 0-100%
Blue: 0-100%
0-255
Value Function
Dimmer: 0-100%
0-255
0-255 Red: 0-100%
0-255 Green: 0-100%
0-255 Blue: 0-100%
Value Function
0-255 Red: 0-100%
Green: 0-100%
0-255
0-255 Blue: 0-100%
0-255 Warm White: 0-100%
6 PARCOB150-MKIII/PARCOB100HEX
