Beveltools Bevel Mite EBI-06 Betriebsanleitung Seite 11

No. Part Name
102 Insulating case
105 Switch cap
107 Carbon brush holder
108 Leg spring
109 Switch knob
110 Switch rods
111 Switch
113 Fan cover
114 Damping ring
115 Ball bearing
116 Ball bearing
117 Spacer bush
118 Annular magnet
119 Washer
120 Countersunk head screw
121 Anti-kink guard
122 Cable clip
123 PT screw
124 Nut
125 Screw
203 Stator complete 230V
203 Stator complete 120V
205 Armature with fan 230V
205 Armature with fan 120V
413 Electronic control 230V
413 Electronic control 120V
Art. No. No. Part Name
9130023 432 Power cable complete 230V
9130020 432 Power cable complete 120V
9130039 461 Carbon brush 230V
9130052 461 Carbon brush 120V
9130051 500 Insulating adapter flange
9130050 502 Neck part
9130036 504 Spacer sleeve
9130045 506 Spindle
9130049 509 Ball bearing
9130041 510 Ball bearing
9230036 511 Seeger J
9130048 512 Belleville washer
9230027 513 Cover hose
9230026 514 Spring lockwasher
9230025 515 Locking ring
9230031 516 Slide block mount
9230017 517 Slide block
9230020 518 Setscrew
9130058 519 Cylindrical pin
9130057 520 Sheet metal screw
9130024 521 Pinion
9130015 522 Internal ring gear
9130011 523 Hanger
9130010
9130016
9130017
11
Art. No.
9130001
9130032
9130008
9130043
9130025
9130006
9130029
9130007
9130038
9130027
9130046
9130054
9130035
9130042
9130005
9130004
9130002
9130003
9120011
9130056
9130014
9130044
9130034
