Specifications
Global
Display Backlit LCD
Main Menus PROG, FX, GLOBAL, COMPARE, WRITE
Edit Menus ARP/SEQ, LFOs, OSCs, POLY, VCF, VCA,
VCA ENV, VCF ENV, MOD ENV, MOD MATRIX
Presets 8 banks each with 128 programs
Fader Modes MIDI CC, NRPN, OFF
Controls
Encoders 1 rotary knob
Faders 26 slide faders (35 mm)
Switches 31 backlit switches
Connectivity
MIDI In/Out/Thru 5-pin DIN / 16 channels
Pedal/CV ¼" TRS
Sustain ¼" TS
USB USB 2.0, type B
Output L/R ¼" TRS, balanced, max. +18 dBu
Headphones ¼" TRS, unbalanced, max. +21 dBu
Synthesizer Architecture
Number of voices 12 analog
OSC 2 per voice
LFO 2 per voice
VCF 2-pole / 4-pole
HPF (Common to all voices) 6 dB per octave
Envelopes VCA, VCF, MOD
Mod Matrix 22 sources / 130 destinations
Digital Effects
FX Slots 4 per Program
FX Types 34 Algorithms
Internal effects engines 1 true stereo SHARC DSP
Effects signal processing 32/40-bit floating point @ 48 kHz
A/D-D/A performance 24-bit 48 kHz, 114 dB dynamic range
Bypass True hard bypass
USB
Type Class compliant USB 2.0, type B
Supported Windows 7 or higher**
operating systems Mac OS X 10.6.8 or higher
iOS 8 or higher (iPad)
Android 6.0 or higher
Wi-Fi
Antenna Internal
Access Point,
Max. 1
number of clients
IEEE 802.11 b/g standard 2.4 GHz
Frequency Range 2,412 - 2,462 MHz
WLAN channels 11
Max Output Power 16 dBm (802.11 b) / 20 dBm (802.11 g) /
20 dBm (802.11 n)
Power Requirements
Mains connector Standard IEC receptacle
Power consumption 55 W max.
Internal Switch-mode PSU Autorange 100-240 V, (50/60 Hz)
Environmental
Operating
5°C – 40°C (41°F – 104°F)
temperature range
Physical (Packaged)
Dimensions (H x W x D) 116 x 461 x 224 mm
Weight 5.0 kg
Shipping Weight 5.9 kg
