eering Wheel: Controls le ft / right motion (note that
-hand use (see full online manual for details).
ttle Trigger: Controls forward / r everse / brak e
Hand Grip: For holding the transmitter.
enna: Transmits signal t o the receiver located in the
ehicle.
r switch: Turns the transmit ter ON / OF F.
Disassemble key ：Handle is removable.
Disassemble Handle & Instal l
1.Press the butto n
2.take away the handl e
3.press the button, install the handl e
www.modster.at
15
14
7. CH3-EPA+/ -
Please put CH4 in the middle of before you press the
CH3 EPA+/-,then press EPA+/-, you can adjust the angle of S T
8. CH4-EPA+/ -
Please put the CH4 switch on left or right, then press
the EPA+/- and adjust the angl e
9. Battery compartment: Houses [4] AA bat teries
10. Channel 3 key .
11. Multifunction Red Indicator LED:
12 .R EV:
(1). Please turn the wheel to left or right with Max angle , and
press REV for 2 seconds,you can hear "DI DI", then ST will
be reverse
(2). Please pull the throttle or push the throttle to Max position ,
and press REV for 2 seconds, you can hear "DI DI",then throttle
will be revers e
(3). Please press CH3 and REV together for 2 seconds, you can
hear "DI DI", then channel 3 will be revers e
(4). Please press REV for 2s, then turn on the CH4, and press
the REV for 2s again, then turn off the CH4
13 . ST DR/ST TRIM: Please turn the wheel to left or right with
Max angle, and press ST-TRIM+ or ST-TRIM-, then adjust
the angle of ST
14 . TH DR/TH TRIM: Please pull the throttle or push the throttl e
to Max position, and press TH-TRIM+ or TH-TRIM-, the n
adjust the angle of T H
When you adjust TRIM +/-, you can sound "Di", when the tri m
is on centre, you can sound "Di-Di"; when the sound is stopped
then means TRIM is Max/Mi n
When you adjust DR +/-, you can sound "Di", when the sound
is stopped, then means DR is Max/Min
15 . Channel 4 key .
