Original operating manual
1 Technical data
Cordless drill
Motor voltage
Idling speed*
Max. torque
soft/ hard material
Adjustable torque**
Chuck clamping range
Drill diameter max.
Wood/ Metal
Weight
* Speed specifications with fully charged bat-
tery pack.
Charger
Mains voltage (input)
Mains frequency
Charging voltage (output)
Rapid charging
Conservation charging, intermittent (NiCd, NiMH)
Charging times for
Li-ion 1.5 Ah, 80 %/100 %
Permitted operating temperature range
Temperature monitoring

Battery pack

Voltage
Capacity
Weight
2 Symbols
Warning of general danger
Risk of electric shock
Read the Operating Instructions/
Notes!
1st gear
2nd gear
3rd gear
4th gear
1st gear
2nd gear
3rd gear
4th gear
** The maximum speed is reduced in the
lower torque stages.
Wear ear protection.
Wear protective gloves.
Wear protective goggles.
9
DRC 18-4 Compact
DRC 18-4 Compact
18 V
0 - 400 rpm
0 - 850 rpm
0 - 1850 rpm
0 - 3800 rpm
28/ 50 Nm
0,75 - 12 Nm
0,6 - 7,5 Nm
0,55 - 5 Nm
0,5 - 2,7 Nm
1,5 - 13 mm
50/ 12 mm
1,7 kg
BCL 3
220 - 240 V ~
50/60 Hz
10.8 - 18 V=
max. 3 A
approx. 0.06 A
approx. 25/35 min.
-5 °C to + 45 °C
with NTC resistor
BP 18 1,5 Ah LiIon
18 V
1,5 Ah
0,4 kg
GB
