GB
DRC 18-4 Compact
LED red – flashing: indi-
cates a general fault, e.g.
incomplete contact, short
circuit, battery pack faulty,
etc.
7 Settings
WARNING
Risk of injury
Always switch off the machine before ad-
justing settings!
7.1 Changing direction of rotation
[1-7]
• Switch to the left = clockwise rotation
• Switch to the right = counterclockwise ro-
tation
7.2 Changing gear
You can change gear using the gear switch
[1-5].
7.3 Adjusting the torque[1-6]
Fastening
Select the correct torque setting:
Position 1 = low torque
Position 12 = high torque
An acoustic signal sounds when the preset
torque is reached and the machine then
switches off. You must release and press the
ON/OFF switch [1-4] again to start the ma-
chine.
Drilling
Mark is aligned with drill symbol
mum torque.
7.4 Changing tools
Turn the clamping sleeve [5-1] anticlock-
wise to open the jaws. The arrow on the
clamping sleeve indicates the opening direc-
tion. The tool can now be inserted into the
drill chuck.
CAUTION
Risk of injury
Clamp the tool centrally in the drill chuck!
Turn the clamping sleeve [5-1] clockwise to
clamp the tool securely
8
8.1
Press = ON, release = OFF
The speed of the machine depends on
how far the on/off switch is pressed in.
8.2
Magnetic, for storing bits and bit holders.
8.3
The user can attach the machine to work
clothing for short periods using the belt clip
(right/left).
8.4
Acoustic warning signals sound and the ma-
chine switches off in the following operating
states:
– Preset torque reached.
– "Block protect" - starting torque too
peep
high.
– Machine overloaded
9
Note the following information:
– Keep the ventilation slits on the machine
free and clean to ensure adequate cooling.
– Keep the contacts on the machine, charger
and battery pack clean.
Information on battery packs
– Store in a cool, dry place at a temperature
between 5 °C and 25 °C.
– Protect battery packs from moisture, water
and heat.
– Do not leave flat battery packs in a charger
disconnected from the mains power supply
= maxi-
for longer than one month. Danger of deep
discharge!
– If you intend to store li-ion battery packs
for longer periods without use, you should
charge them to 40 % capacity (approx. 15
min charging time).
9.1
service point
EKAT
3
2
1
12
Working with the machine
On/Off switch [1-4]
Bit depot [1-1]
Belt clip [1-8]
Acoustic warning signals
Service and maintenance
After-sales service and repair
Always contact the manufacturer
or an authorised service work-
shop.
Visit www.protool-online.com/
service to locate your nearest
Always use original Protool spare
4
parts!
