FiberMASTER
Fiber Optic Testing Kit
Instruction Manual
Introduction
The IDEAL FiberMASTER
the user to measure absolute power and calculate the
loss of fiber optic links at several wavelengths. Absolute
power measurements are helpful when trouble shooting
equipment that may not be operating properly. The dB
calibration feature allows the operator to set a reference
level to the light source and directly read the loss of fiber
optic links without needing to manually calculate the values. The unique form
factor allows the light source to be docked neatly within the power meter. This
makes the kit compact for easy storage while still allowing full operation of both
the source and meter.
Product Features
• 850, 1300/1310, 1490 and 1550 wavelength measurement capability
on power meter
• 850/1300/1310/1550nm laser light source (33-931 kit)
• Power measurement in dBm and µW, loss display in dB
• Power meter auto power off
• Operates on standard AAA batteries, three in each unit
• Includes universal adapter for power meter and ST, SC and FC adapters
for light source
• Includes rugged carrying pouch, multimode and single mode SC jumpers
and calibration coupler
TM
fiber optic testing kit allows
TM
1
#33-931
