Technical Specifications - Evolveo StrongVision PRO Bedienungsanleitung

3. Technical Specifications

3.1 General
Display
Movement sensor
Detection angle of the
movement sensor
Night illumination
IR LED beam distance
Dimensions
Operating
temperature
Storage temperature
Ingress protection
Security
Operating
temperature
* Night images may be dark if there are no other objects in the
area in front of the camera from which the IR illumination may be
reflected. Ideally, there should be objects in the area in front of
the camera from which the IR illumination can be reflected, such
as stones, shrubs, trunks and the like. The optimal beam distance
is 8–12 m from the camera
** Including a mounted antenna bent to 90°, height including a
straightened antenna 347 mm
Colour TFT 2.4"
PIR (Passive Infrared) – adjustable
sensitivity (3 levels)
120°
IR LED 940 nm, 58 LED under the
front antireflective cover
20 m *
H x W x D 187** x 118 x 87 mm
-10°C to +50°C
-15°C to +60°C
IP65
4-digit optional password
-10°C to +55°C
68
