Warnings – Assembly text instructions – Maintenance
English
WARNINGS
General
• Do not use any sharp tools to open the
packaging.
• We strongly advise against using power tools.
• Tripping hazard, mind your step.
• Do not put out cigarettes on the table.
• Not grafitti proof.
• Do not leave children unattended whilst playing
on the table.
• away from babies and children.
• Colors can differ over years and from batch to
batch.
Product
• Do not drag the table, but carry it with minimum
2 people.
• Anchoring the product has to be done by
qualified people.
• For anchoring: use suitable bolts or screws from
a specialized store depending on the material
your terrace is made of.
Powder coating
• White powder coating requires more
maintenance.
• Do not use abrasive scouring powders or
scourers as they will scratch the surface.
• Color can fade to some extent when exposed to
UV.
• Flame retarding - NEN-EN13501-1 A2-sl -
Satisfying the same criteria as Class B for the
SBI-test according to EN13823. In addition,
under conditions of a fully developed fire these
products will nog significantly contribute to the
fire load and fire growth.
• Dark colors can get very hot in sunny weather.
ASSEMBLY INSTRUCTIONS
Lighting & electricity module - p6
1. Remove the side plate with hole by unscrewing
the four bolts and set everything aside.
2. Remove the large cover plate from the top profile.
3. Slide the lighting & electricity module in the
top profile. Attention: make sure the lighting &
electrification is facing downwards.
4. Reattach the side plate with the four screws.
16
Attention: make sure the electricity cable goes
through the hole of the side plate.
Position the top profile between the two A-frames.
a. Make sure the electricity cables goes through
the hole of the A-frame and faces towards the
socket you want to use. Connect the power
supply to this connector.
b. Slide the top profile over the adjusting screws
so that it is correctly located so that it already
stays in place.
c. First screw an M10 cap nut & washer onto the
two adjusting screws to hold the top profile in
place.
5. Make sure the lighting & electricity module is
centered. Now insert two small cover plates to
the top profile, left and right next to the lighting
& electricity module, with the recess facing
outwards as shown in the drawing.
Now go back the step 5 of the manual LAB152.
Connecting multiple lighting & electricity
modules - p10
1. Remove the side plate with hole by unscrewing
the four bolts and set everything aside.
2. Remove the large cover plate from the top profile.
3. Slide the lighting & electricity module in the
top profile. Attention: make sure the lighting &
electrification is facing downwards.
4. Reattach the side plate with the four screws.
Attention: make sure the electricity cable goes
through the hole of the side plate.
5. Position the top profile between the two A-frames.
a. Make sure the electricity cables goes through
the hole of the A-frame and faces towards the
socket you want to use. Connect the power
supply to this connector.
b. Slide the top profile over the adjusting screws
so that it is correctly located so that it already
stays in place.
c. First screw an M10 cap nut & washer onto the
two adjusting screws to hold the top profile in
place.
6. Then repeat the procedure for the second top
profile and attach the two lighting & electricity
module to each other. Attention: male to female
as shown in the drawing.
7. Now screw an M10 cap nut & washer onto the
adjusting screws to hold the top profile in place.
8. Make sure the lighting & electricity module is
centered. Now insert two small cover plates to
the top profile, left and right next to the lighting
& electricity module, with the recess facing
