• Use only the fixing screws supplied with
the product for installation or, if not supplied,
purchase the correct screws type.
• Use the correct length for the screws which
are identified in the Installation Guide.
• In case of doubt, consult an authorized
service assistance center or similar qualified
person.
WARNING! Do not use with a
programmer, timer, separate remote
control system or any other device that
switches on automatically.

Electrical connection

The mains tension must correspond to the tension shown on the
characteristic label situated inside the hood.
The product is meant for connecting directly to the mains supply,
therefore apply a regulation bipolar switch that ensures complete
disconnection from the mains in the conditions of category III over-
tension, conforming to the installation rules.
Warning! Detail B is equipped with a conductor (yellow-green)
that must be connected to the earth of the domestic electrical
plant. Fig. 6a-b
Warining! Changing the interconnection cable must be carried out
by the authorised technical assistance service.

Installation

• The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the range hood
must be not less than 60cm from electric cookers and 70cm from gas
or mixed cookers.
If the instructions for installation for the gas hob specify a greater
distance, this must be adhered to.
Specialised personnel must carry out both the electrical and the
mechanical installation.
• This appliance is marked according to the European directive
2012/19/EC - UK SI 2013 No.3113 on Waste Electrical and
Electronic Equipment (WEEE).
• By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate
waste handling of this product.
• The symbol on the product, or on the documents
accompanying the product, indicates that this appliance may not be
treated as household waste. Instead it should be taken to the
appropriate collection point for the recycling of electrical and
electronic equipment. Disposal must be carried out in accordance
with local environmental regulations for waste disposal.
• For further detailed information regarding the process, collection and
recycling of this product, please contact the appropriate department
of your local authorities or the local department for household waste
or the shop where you purchased this product.
Appliance designed, tested and manufactured according to:
• Safety: EN/IEC 60335-1; EN/IEC 60335-2-31, EN/IEC 62233.
• Performance: EN/IEC 61591; ISO 5167-1; ISO 5167-3; ISO 5168;
EN/IEC 60704-1; EN/IEC 60704-2-13; EN/IEC 60704-3; ISO 3741;
EN 50564; IEC 62301.
• EMC: EN 55014-1; CISPR 14-1; EN 55014-2; CISPR 14-2; EN/IEC
61000-3-2; EN/IEC 61000-3-3. Suggestions for a correct use in order
to reduce the environmental impact: Switch ON the hood at
minimum speed when you start cooking and kept it running for few
minutes after cooking is finished. Increase the speed only in case of
large amount of smoke and vapor and use boost speed(s) only in
extreme situations. Replace the charcoal filter(s) when necessary to
maintain a good odor reduction efficiency. Clean the grease filter(s)
when necessary to maintain a good grease filter efficiency. Use the
maximum diameter of the ducting system indicated in this manual to
optimize efficiency and minimize noise.
Use
The hood has been made for use in the internal recirculating filtering
version.
Cooking fumes and steam are aspirated inside the hood, filtered and
cleaned, passing through the fat filter/s and the carbon filter/s that
MUST be supplied with the hood.
Mounting
This type of cooker hood must be fixed to the ceiling.
Very heavy product; hood handling and installation must be
carried out by at least two persons.
Expansion wall plugs are provided to secure the hood to most types
of walls/ceilings. However, a qualified technician must verify suitability
of the materials in accordance with the type of wall/ceiling. The
wall/ceiling must be strong enough to take the weight of the hood.
Do not tile, grout or silicone this appliance to the wall. Surface
mounting only.

Operation

This product is designed to work with an Elica remote control, either
supplied with the product or purchased separately as an optional.
To control the hood via remote control, the affiliation procedure must
be carried out.
