14
ULTRALINK MS8000
Specifications
Audio Inputs
Connectors
8 x XLR
Impedance
1 kΩ, balanced
Max. input level
30 dBu @ 1 kHz
Link
Controls
Lift/Ground
Audio Outputs
Link connectors
8 x XLR, parallel to inputs
Direct out connectors
8 x XLR
Voltage transformation ratio
1 : 1.2
Impedance
2.7 kΩ, balanced
Max. output level
38 dBu @ 1 kHz
System
Frequency response
30 Hz to 30 kHz (±0.5 dB @ +4 dBu)
THD + N (Distortion)
0.02% @ 1 kHz, input level +4 dBu
Signal-to-noise ratio
104 dBu
CMRR
>80 dB, typical
+8 dB @ 100 kΩ
Insertion loss
-5 dB @ 600 Ω
Power requirement
Passive
Dimensions/Weight
Dimensions (H x W x D)
44 x 483 x 65 mm (1.7 x 19.0 x 2.6")
Weight
1.1 kg (2.4 lbs)
Other important information
Important information
1. Register online. Please register your new
MUSIC Tribe equipment right after you purchase it by
Registering your purchase using
our simple online form helps us to process your repair
claims more quickly and efficiently. Also, read the terms
and conditions of our warranty, if applicable.
2. Malfunction. Should your MUSIC Tribe
Authorized Reseller not be located in your vicinity,
you may contact the MUSIC Tribe Authorized Fulfiller for
your country listed under "Support" at
Should your country not be listed, please check if your
problem can be dealt with by our "Online Support" which
may also be found under "Support"
Alternatively, please submit an online warranty claim at
BEFORE returning the product.
3. Power Connections. Before plugging the
unit into a power socket, please make sure you are using
the correct mains voltage for your particular model.
Faulty fuses must be replaced with fuses of the same type
and rating without exception.
15
Quick Start Guide
