BAD BATTERY (red) LED lit: The charger has detected a problem with the battery. See
troubleshooting section for more information.
6.1.3 Charging the internal battery using the included wall charger.
Only use the charger that was included with the booster to charge the internal battery
IMPORTANT
of the booster. Using any other charger or using the included charger for any other
purpose could result in personal injury or property damage.
6.1.4 This battery charger is for use on a nominal 230V 50 Hz circuit. The plug must be plugged into
an outlet that is properly installed in accordance with all local codes and ordinances. The plug pins
must fit the receptacle (outlet).
6.1.5
Never alter the AC cord or plug provided – if it does not fit the outlet, have a proper
/!\ DANGER
outlet installed by a qualified electrician. An improper connection can result in a risk
of an electric shock or electrocution.
6.1.6 An extension cord should not be used unless absolutely necessary. Use of an improper
extension cord could result in a risk of fire and electric shock. If an extension cord must
be used, make sure:
-That the pins on the plug of the extension cord are the same number, size and shape
as those of the plug on the charger.
-That the extension cord is properly wired and in good electrical condition.
-That the wire size is large enough for the AC ampere rating of the charger.
Recommended minimum cross-section size for extension cord:
-30.5 meters long or less – use a 1.0 mm² extension cord.
-Over 30.5 meters long – use a 1.25 mm² extension cord.
6.1.7 Charging
Make sure that both the charger and booster are placed on a dry, nonflammable surface. To
charge the booster, connect the charger included into the charging port that is located at the
front of booster.
Confirm the AC outlet voltage matches the input voltage of the charger.
1.
Connect the charger into the electrical wall outlet and confirm that the Green POWER LED
on the charger turns on.
2.
Check that the yellow CHARGING LED in charger starts flashing slowly to indicate that charge
process has started. To know status of the charge, check the percentage shown at the display
in booster.
3.
When the display in booster shows 100 (%), the internal battery is fully charged and the
booster is ready to use. Complete charging may take up to 24 hours.
NOTE: The yellow CHARGING LED on the charge will remain flashing after display shows
100%, because charger enters automatically into maintaining mode.
All manuals and user guides at all-guides.com
RISK OF ELECTRIC SHOCK OR FIRE.
