Parts

Rod
1
2
Fig. 7: Connecting the rods
Rotary head
3
Fig. 8: Parts of the Universal Rotary
Head
4 5
1 Male connector with snap straps
2 Female connector
3 Rotating body with M 10 female thread,
for holding the star grip screw or an op-
tional cleaning tool with M 10 thread
4 Clamping part
5 Star grip screw
