INSERT A70 (FRONT)
C
D
B
I
L
A Pellet hopper
B Opening handle
C Door
D Closing hook
E Ash compartment
F Burn pot
G Combustion chamber
H Flue gas fan
004778740 - 14/06/2021
ITALIANO ENGLISH
G
E
F
FRANÇAIS
P
H
O
M
Q
I Smoke outlet pipe
L Loading system
M Manual reset thermostat
N Faulty
O Room sensor
P Room fan
Q Microswitch
R Power cable
DEUTSCH ESPAÑOL
A
R
N
Fig. 4
