English
Application
In­house telephone for­Siedle
In­Home bus with WLAN interface
for mobile extension through the
Siedle app.
With the call, speech, door release
and light functions on the indoor
station and on a smartphone with
the Siedle app.
The storey call is also available on
the in­house telephone.
Performance features:
• 2.4 GHz WLAN interface for the
Siedle app
• Bluetooth 4.2 interface for com­
missioning
• Integrated door release and light
button
• Integrated hearing protection,
audio privacy function
• Muting and status display
• Light button and muting button
can be freely configured and double
assignment possible
• Call generator with 11 ring tone
sequences, including chime
• Call volume adjustable in 5 stages
up to max. 83 dB(A)
• Automatic update function when
Internet connection is active
• The Siedle app behaves like an
indoor device connected in parallel
for the call
If the operating voltage is not con­
nected, the WLAN interfaces will
not work.
Electrical voltage
Mounting, installation and servicing
work on electrical devices may only
be performed by a suitably qualified
electrician.
4
Electrostatic charging
As a result of electrostatic charging,
direct contact with the circuit board
can result in destruction of the
device.
Direct contact with the circuit board
must therefore be avoided.
Note
For use only in dry indoor atmos­
pheres.
Scope of supply
• IQ BTS (base plate and housing
with circuit board)
• Receiver
• Spiral cable
• Operating instructions for the
end user
• This product information
Terminal assignment
Ta, Tb In­Home bus
ERT Storey call button
DC, DC Operating voltage
Mounting
Strip back cable to appr. 80 mm.
1 Recommended mounting height
appr. 1.50 m/4.9 ft to centre device.
2 Open the device from the back
by releasing the base plate with the
locking Lever.
3 When mounting directly on the
wall, fasten the base plate using
4 screws, paying attention that
the plate is the right way up (top
marking).
4 When mounting on a switch box,
use the screw openings in the centre
of the device, paying attention that
the plate is the right way up (top
marking).
5 Install in accordance with the
wiring diagram. The cores of the
installation cable must be stored
inside the free installation space in
the base plate.
6 Insert the coloured plug of the
spiral cable into the socket at the
housing. A distinct click is audible
when the plug is correctly inserted.
7 Insert the other end of the spiral
cable into the receiver until the plug
clicks audibly into place. This con-
nection can no longer be detached.
8 Hook the housing into the base
plate from above and close by
exerting a slight pressure.
Dismantling
9 To remove the housing, press
the lock upwards using a flat blade
screwdriver. The circuit board and
receiver remain on the upper part of
the housing.
Circuit diagram
10 Wiring diagram with additional
central supply. One PSM 1 12 24
supplies a maximum of 1 IQ BTS.
11 Wiring diagram with power
supply unit.
12 Wiring diagram with additional
central supply.
One NG 706-30/33-... supplies a
maximum of 8 IQ BTS. Alternatively,
an NG 602-... can be used, this sup-
plies a maximum of two IQ BTS.
Commissioning Bus
The programming is described in
the Siedle In­Home bus system
handbook, it behaves in an identical
manner to BTS 850-...
Commissioning App
See operating instructions.
Specifications IQ BTS
Operating voltage: 12–30 V DC
Operating current: max. 300 mA
Ambient temperature:
+5 °C to +40 °C
Dimensions (mm) W x H x D:
91 x 201 x 48
