Safety Instructions - Milwaukee MS 304 DB Originalbetriebsanleitung

TECHNICAL DATA
MITRESAW
Production code
Rated input
Amps
No-load speed
Saw blade dia. x hole dia
Saw blade thickness
Max. cutting width
Mitre 0°/ Bevel 0°
Mitre 45°/ Bevel 0°
Mitre 0°/ Bevel 45°
Mitre 0°/ Bevel 45°
Mitre 45°/ Bevel 45°
Mitre 45°/ Bevel 45°
Max. height
Mitre 0°/ Bevel 0°
GB GB
Mitre 45°/ Bevel 0°
Min. workpiece dimensions
Weight according EPTA-Procedure 01/2003
Noise/Vibration Information
Measured values determined according to EN 61029. Typically, the A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3 dB(A))
Sound power level (Uncertainty K=3 dB(A))
Wear ear protectors!
Total vibration values (vector sum in the three axes) determined according to EN 61029.
Vibration emission value a
Sawing of wood
Uncertainty K=
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 61029 and
may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with
different accessories or poorly maintained, the vibration emission may differ. This may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is running
but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
WARNING! Read all safety warnings and all instruc-
tions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.

SAFETY INSTRUCTIONS

Wear ear protectors. Exposure to noise can cause hearing loss.
Always wear goggles when using the machine. It is recommended to
wear gloves, sturdy non slipping shoes and apron.
The dust produced when using this tool may be harmful to health.
Do not inhale the dust. Use a dust absorption system and wear a
suitable dust protection mask. Remove deposited dust thoroughly,
e.g. with a vacuum cleaner.
Appliances used at many different locations including open air should
be connected via a residual current device (FI, RCD, PRCD) of 30mA
or less.
Before doing any work on the machine, pull the plug out of the
socket.
English English
22
All manuals and user guides at all-guides.com
MS 305 DB
230 V / 240 V
4115 51 01 ...
4102 06 01 ...
4476 45 01 ...
4476 51 01 ...
... 000001-999999
1800 W
8 A
3200 min
305 x 30 mm
2,4 mm
102 / 342 mm
102 / 241 mm
57 / 342 mm
45 / 342 mm
57 / 241 mm
45 / 235 mm
166 / 53 mm
166 / 10 mm
130 x 35 x 2 mm
30,2 kg
95 dB(A)
108 dB(A)
h
< 2,5 m/s
1,5 m/s
MS 305 DB MS 304 DB
110 V 230 V / 240 V
4102 11 01 ... 4333 41 01 ...
4476 48 01 ... 433351 01 ...
... 000001-999999 ... 000001-999999
1800 W 1800 W
15 A 8 A
3200 min 3900 min
-1 -1
305 x 30 mm 305 x 30 mm
2,4 mm 2,4 mm
102 / 342 mm 102 / 342 mm
102 / 241 mm 102 / 241 mm
57 / 342 mm 57 / 342 mm
45 / 342 mm 45 / 342 mm
57 / 241 mm 57 / 241 mm
45 / 235 mm 45 / 235 mm
166 / 53 mm 166 / 53 mm
166 / 10 mm 166 / 10 mm
130 x 35 x 2 mm 130 x 35 x 2 mm
30,2 kg 29,9 kg
95 dB(A) 93,5 dB(A)
108 dB(A) 105 dB(A)
< 2,5 m/s 3,3 m/s
2 2
1,5 m/s 1,5 m/s
2 2
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine. Always
lead the cable away behind you.
Before use check machine, cable, and plug for any damages or
material fatigue. Repairs should only be carried out by authorised
Service Agents.
The handle lock must always be engaged when transporting the
mitre saw.
Ensure that the machine is always stable and secure (e.g. fixed to a
bench).
Keep the floor area free of loose material e.g. chips and cut-offs.
Before using the tool please read the instructions. If possible have the
tool demonstrated.
Always use the protective shields on the machine.
Only use the saw with guards in good working order and properly
maintained, and in position.
Do not clamp the protective swing guard.
MS 304 DB
110 V
4333 56 01 ...
... 000001-999999
1800 W
15,5 A
3900 min
-1 -1
305 x 30 mm
2,4 mm
102 / 342 mm
102 / 241 mm
57 / 342 mm
45 / 342 mm
57 / 241 mm
45 / 235 mm
166 / 53 mm
166 / 10 mm
130 x 35 x 2 mm
29,9 kg
93,5 dB(A)
105 dB(A)
3,3 m/s
2 2
1,5 m/s
2 2
