Technical specifications

Electrical data 12 V

Identifier
Rated voltage
Power consumption
Rated current consumption for exter-
nal consumers
Safety fuse F1
Safety fuse F2
Contact loading capacity (relay)
· with resistive load

Technical data 12 V

Identifier
Dimensions (W x H x D)
Emergency switching element
Light emitting diodes
Degree of protection according to
DIN EN 60529
Ambient temperature
Installation position
Value
12 V DC (±10 %) SELV
max. 200 mA
max. 1 A
1.6 A slow blow (small safety fuse series
372/374; Wickmann, type TR.5)
0.1 A slow blow (small safety fuse series
372/374; Wickmann, type TR.5)
max. 24 V / 1 A
Value
Surface-mounted version
92.5 mm x 250,0 mm x 98.0 mm
Flush-mounted version
122.0 mm x 280.0 mm x 100.0 mm
In accordance with DIN EN 60947 5-5
Red, green, yellow
IP 20
0 °C to 35 °C
Vertical
