Angle function 2:
Angle
function 2
The measurement results are determined automatically by the 360°
inclination sensor.
!
The back of the device can be used as a reference surface
for measuring angles.
Angle function 3:
Angle
function 3
The measurement results are determined automatically by the 360°
inclination sensor.
!
The back of the device can be used as a reference surface
for measuring angles.
Digital bubble level:
The digital bubble level is used to horizontally align the measuring device.
Tilt sensor calibration:
To calibrate the tilt sensor follow the instructions on the display.
LaserRange-Master i5
1. measurement 2. measurement
1x 2x
1. measurement 2. measurement
1x 2x
3x 4x
3x 4x
Results
Results
