Doepke
Rated current (per output)
Rated current (per output)
Figures for no. of switching cycles
Fluorescent lamps, uncompensated
Fluorescent lamps, parall. compens.
Fluorescent lamps, load-lag circuit
LV halogen lamps w. transformer
HQL, parallel compensated
DULUX lamps, uncompensated
DULUX lamps, parall. compensated
Terminals
Housing
General technical data
Order number, description 09 501 174, 4-way relay module DSM 4M
a. These data relate to connection requirements in accordance with EN 60669.
Switching cycles for lamps not listed here are available upon request.
3931227/2013.05/G - The right to make technical changes reserved!
Voltage
Voltage
Incandescent lamps
Halogen lamps, 230 V
HQL, uncompensated
Type Strain-relief terminals
Contact area
Torque
Type Distribution installation housing for mounting
Dimensions 72 x 85 x 58 (B x H x T in mm) / 4 modules
Material Polycarbonate
Ambient temperature
Atm. humidity max. 85% (exposure to dew not permissible)
Encl. protection type IP20
Min.
Typ.
12 VAC
100 mA
12 VDC
100 mA
30,000
2500 W
2500 W
1300 W / 140 µF
2 x 2500 W
2500 W
500 VA
2000 W
2000 W / 140 µF
1600 W
1300 W / 140 µF
0.4 mm ∅
on rails according to DIN EN 60715:2001-09
-10°C
Max.
250 VAC
16 A
30 VDC
10 A
100,000
1250 W
1250 W
650 W / 70 µF
2 x 1200 W
1200 W
500 VA
1000 W
1000 W / 70 µF
800 W
1300 W / 140 µF
2.5 mm²
0.6 Nm
+45°C
7
