Technical Data

Subwoofer
Dimensions of subwoofer in cm
Weight subwoofer in kg
Digital output stages
Principle
Fitting
Load capacity subwoofer
Satellite channels
Mains voltage
Max. power consumption
Nominal power consumption
Power consumption on standby
Bass intensity
Transmission range
Phase switch
Power switch
System link
Satellite loudspeakers
Dimensions satellite loudspeakers in cm without/with stand
Weight satellite loudspeakers in kg without/with stand
Principle
Fitting
Load capacity
Impedance
Transmission range
Sound pressure
Standing speaker
Dimensions standing speaker in cm
Weight standing speaker in kg
Principle
Fitting
Load capacity
Impedance
Transmission range
Sound pressure
- 22
W 43,3 x H 25 x D 34,3
6 channels
1 way bass refl ex, active
1x bass 200 mm
100 (sine) /150 Watt (max. music)
50 (sine) /65 Watt (max. music)
220 – 240 Volt
250 Watts
50 Watts
< 0,5 Watts
38 Hz–250 Hz ± 3dB
Audio Link 25-pole D-Sub
Cubic socket 9-pin JST
W 6,2 H 15 x D 6,2 / Stand Ø 20 x H 100,5
0,7 / 3,3
3 way bass refl ex, d'Appolito arrangement
2x broadband, paper diaphragm, Ø 55mm
50 W (sine) / 50 W (max. music)
150 Hz–20 kHz ± 3dB
86 dB spl (1w/m)
Ø 26 x H 112,5
3 way bass refl ex, d'Appolito arrangement
2x bass 80 mm, paper diaphragm
2x broadband 80 mm, paper diaphragm
1x treble, coated fabric calotte, Ø 33mm
75 W (sine) / 120 W (max. music)
4 -8 Ohm
75 Hz–22 kHz ± 3dB
84 dB spl (1w/m)
13,2
±12 dB
yes
yes
8 Ohm
11,1
CH/0710/A2
