Product information

3.1

Application

The water softening system is suitable for use
with cold drinking water having a maximum
water temperature of up to 30 °C.
ATTENTION
(see chapter 1.2 "Safety instructions and
dangers due to non-observation")
Usage limitations see chapter "Intended
use".
This water softening system is for protection
of water pipes and the water heater against
limescale deposits.
With partially softened water, devices and fit-
tings are preserved and the consumption of
washing and cleaning agents reduced.
Limescale deposits block the water
supply and therefore can result in in-
creased energy consumption.
3.2

Approval marks

Fig. 3 : DIN-DVGW marks
The devices comply with the technical regu-
lations for drinking water installation accord-
ing to DIN EN 806 ff. and the national sup-
plement DIN 1988 ff. as well as DIN
EN 1717. They have been tested and ap-
proved by the DVGW (German Technical
and Scientific Association for Gas and Wa-
ter) according to the requirements of DIN
EN 14743 and DIN 19636-100 for water sof-
tening systems (cation exchangers) and can
thus bear the DIN-DVGW mark.
34
Product information
3.3

Materials used

The materials used are resistant to the phys-
ical, chemical and corrosive loads expected
to be encountered in drinking water and fulfil
the specifications
EN 14743 and DIN 19636-100 ('Water sof-
tening systems (cation exchangers) in drink-
ing water installations'). All materials are hy-
gienically and physiologically harmless.
Plastics fulfil the KTW Guideline (Guideline
for the Hygienic Assessment of Organic Ma-
terials in Contact with Drinking water) of the
German Federal Environmental Agency
(UBA). Metallic materials fulfil the require-
ments of DIN 50930-6 (Effect of metallic ma-
terials on the quality of drinking water).
4

Installation

4.1 Requirements for the place of
installation
The installation room must be dry and
free from frost!
Unauthorised persons must not be able
to access the water softening system.
– The ambient temperature must not ex-
ceed 30 °C!
– A power connection with a permanent
supply, that is independent of the light
switch, must be available ("In operation"
LED (11) always on). Similarly a sewer
connection for the flushing water (3) and
the safety overflow of the brine tank (6).
– The water softening system can be in-
stalled in horizontal or vertical pipes. The
installation height depends on the pipe
course (minimum installation height from
the ground to the rotary flange fitting is
93 cm for a direct connection without
hoses). The salt filling opening which is
closed with a transparent hood (4) must
be readily accessible.
– So that it is possible to safely drain the
waste water (regeneration) during oper-
ation and also in the event that a system
DELFIN MEGA
required by DIN
