BASETech KUC-1000 Bedienungsanleitung Seite 2

Operating Instructions
KUC-1000 Micro USB car charging adapter with
coiled cord
Item No. 2348502
Intended use
The product is designed to charge and operate USB devices in a vehicle. It can also be oper-
ated in trucks with 24V on-board voltage socket. Power supply is via a car cigarette lighter
socket. The product features overload and short circuit protection mechanisms.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bath-
rooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged. In
addition, improper use can result in short circuits, fires, electric shocks or other hazards. Read
the instructions carefully and store them in a safe place. Make this product available to third
parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Micro USB car charging adapter with coiled cord
• Operating instructions
Up-to-date operating instructions
Download the latest operating instructions at www.conrad.com/downloads or
scan the QR code shown. Follow the instructions on the website.
Explanation of symbols
The symbol with the lightning in the triangle is used if there is a risk to your health,
e.g. due to an electric shock.
The symbol with the exclamation mark in the triangle is used to indicate important
information in these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and advice on operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling in this manual, we assume no liability for any resulting per-
sonal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
a) General information
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become dan-
gerous playing material for children.
• Protect the appliance from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, steam and
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Consult an expert when in doubt about the operation, safety or connection of the
appliance.
• Always turn off the connected device before connecting/disconnecting it.
• Unplug the product while it is not in use.
• The product gets hot during use. Ensure sufficient ventilation and never cover the
product during use.
• Do not short-circuit the USB output.
• Never use the product immediately after it has been brought from a cold room
into a warm one. The condensation generated could destroy the product. Allow
the device to reach room temperature before connecting and using it. This may
take several hours.
solvents.
• Never leave the product and the connected device unattended during use.
• Maintenance, modifications and repairs must only be completed by a technician
or an authorised repair centre.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
b) Connected devices
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
Operation
Always turn off the desired device before connecting it to the Micro USB port.
Make sure the connection is correct. If the product is not connected properly,
it could overheat or cause an electric shock or fire.
Make sure that the device meets the product's power requirements (see tech-
nical data).
1. Connect the switched-off USB device to the product.
2. Plug the product into your vehicle's cigarette lighter socket. The power indicator on the
product lights up to indicate the product is operational.
3. Your USB device is now charging. Should you wish to operate the USB device, you may
turn it on now.
4. Turn off the USB device before disconnecting the product from the cigarette lighter socket.
5. Unplug the product from the cigarette lighter socket after use.
You can operate the product while the engine is both on or off. But you should not
start the engine while the product is connected, since the cigarette lighter socket
disconnects during engine start (not necessarily applicable to all vehicle models). If
the engine is switched off, drawing current over a longer period of time will discharge
the vehicle battery.
Replacing the fuse
• Turn the cap on the tip of the product counter-clockwise.
• Remove the defective fuse and replace it with a fuse of the same type (see technical data).
• Replace the cap and tighten it by turning it clockwise.
Care and cleaning
• Unplug the product from the cigarette lighter socket before cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the house-
hold waste. At the end of its service life, dispose of the product in accordance with
applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the environment.
Technical data
Input voltage ................................. 12 – 24 V/DC
Output voltage/current .................. 5 V, 1 A
Standby power consumption ........ 0.12 W
Fuse .............................................. 1 A, 250 V, 6.4 x 31.8 mm, fast acting
Cable length ................................. 1 m
Operating conditions ..................... 0 to +35 ºC, 20 – 90 % RH (non-condensing)
Storage conditions ........................ -20 to +60 ºC, 10 – 90 % RH (non-condensing)
Dimensions (W x H x D) ............... 100 x 42 x 20 mm
Weight .......................................... 60 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2021 by Conrad Electronic SE. *2348502_v2_0421_02_mxs_m_en
