2. Layout (Fig. 1/2)
1 Air inlet
2 IR receiver diode
3 Button for automatic slat adjustment (swing)
4 Button for setting the desired temperature
5 Temperature indicator
6 Indicator for the selected OFF time (timer)
7 Button for setting the heat output
8 On/Standby button
9 Air outlet slats
10 On / Off main switch
11 Compartment for the remote control
12 IR remote control (RC)
13 RC button for setting the OFF time (timer)
14 RC button for ionizer On/Off
Symbols used on the equipment display
A = Automatic slat adjustment (swing)
B = Ionizer
C = Fan
D = Low heat output
E = High heat output
3. Items supplied
Open the packaging and take out the equipment
with care.
Remove the packaging material and any
packaging and/or transportation braces (if
present).
Check to see if all the items are supplied.
Inspect the equipment and accessories for
transport damage.
If possible, keep the packaging until the end of
the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
plastic sheets and small parts. There is a risk of
choking and suffocating!
Wall heater
Remote control (is in the storage compartment)
2 screws and 2 dowels
Original operating instructions
8
20.03.2012 13:21 Uhr Seite 8
4. Intended use
The equipment is designed exclusively for use as an
additional heater in dry, closed rooms.
The equipment is allowed to be mounted only on
vertical walls. The equipment is not suitable for drying
towels and textiles.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Technical data:
Rated voltage:
Output:
Timer:
Negative ions:
Protection type:
6. Before starting the equipment
Read the safety instructions in section 1.
Important! Make sure that there are no electric
cables or other installations (for example water
pipes) near the drill holes. Ensure that the appliance
is firmly and horizontally fitted to the wall. You must
always ensure that a distance of at least 100 cm is
kept between the front side of the heater and other
objects.
Do not let hot air blow onto combustible objects; it is
imperative to observe a distance of 1 m.
Use only suitable fastening material. The supplied
dowels and screws are suitable for the following:
Concrete, natural stone with a dense structure, solid
brick, solid limestone bricks, solid lightweight
concrete bricks and aerated concrete.
Mark the position of the drilled holes (diameter
8 mm, height from the floor at least 200 cm) for
mounting the equipment on the wall.
220-240 V ~ 50 Hz
2000 W (1000 W / 2000 W)
1 to 8 hours
≥ 3x10 6 n/cm 3
IPX0
