8 CMS 1201DCT/1201DC
11.
其他的重要信息
¼ '' TS
13.
14.
15.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
法律声明
12.
MUSIC Group
MIDAS, KLARK TEKNIK, LAB GRUPPEN,
LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC,
TC HELICON, BEHRINGER, BUGERA
MUSIC Group IP Ltd.
© MUSIC Group IP Ltd. 2016
保修条款
music-group.com/warranty
16.
17.
2000
Introduction
Thank you for purchasing this TANNOY product. The CMS 1201DC is a powerful state-of-the-art large format in-ceiling loudspeaker device conceived, designed and
built to complement TANNOY's class-leading CMS range. From the pioneers of point source and large format ceiling speakers the CMS 1201DC is engineered from the
ground up with superior full-range performance in mind to handle demanding distributed sound applications such as ballrooms, shopping malls, sports halls, airports
and other high ceiling installations. Built around a brand new evolution of the high power handling 12" (300 mm) Dual Concentric point source driver, the CMS 1201DC
delivers best-in-class performance for the most even beamwidth and pattern control over the widest range of frequencies of any large format ceiling speaker. Coupled
with exceptional clarity, ultra low distortion, and high SPLs, TANNOY has again raised the bar to give the absolute cutting edge performance in ceiling mounted
loudspeaker technology. The new Dual Concentric drive assembly features a treated mid-bass cone and double rolled cambric surround for high sensitivity, as well as a
DDA
34 mm (1.34") aluminium dome with ferrofl uid-cooled Neodymium magnet assembl and a newly designed waveguide for the high frequency unit. These two drivers
seamlessly merge into one with the high frequency mounted in the throat of the mid-bass; coincidentally aligning both transducers to a point source. The result is a
smooth, uniform response over a very controlled 90 degree coverage area – even in the highest octaves.
Unpacking and Visual Checks
Every TANNOY product and accessory is carefully inspected before packing. After unpacking, please inspect your product to make sure no damage has occurred in
transit. In the unlikely event of any damage, would you please notify your dealer immediately and retain your shipping carton, as your dealer may ask you to return the
faulty unit to him for inspection.

Product Overview

The CMS1201 DC comprises three discrete components that are ordered separately under diff erent part numbers.
• A loudspeaker assembly that includes a Dual Concentric drive unit mounted on a ported steel baffl e, and it crossover. This baffl e may also include a line transformer
(CMS 1201DCt)
• A steel back-can with multiple mounting points
• A grille assembly with its moulded bevel cover
Quick Start Guide 9
