Industrieprotokolle
16.3 EtherNet/IP
Tab. 56:
Id Attribute
0xB Last Conflict
Detected
Tab. 57:
Id Attribute
0x6 Cable Test
4
0x6 Cable Pair Size
5
0x6 Cable Test Result
6
376
Attribute der Instanz 1 (Forts.)
Access
Rule
Get
Hirschmann-Erweiterungen des TCP/IP-Interface-Objekts
Access
Rule
Set/Get STRUCT of:
Get
Get
Data type
STRUCT of:
USINT AcdActivity
ARRAY of:
6 USINT RemoteMac
ARRAY of:
28 USINT ArpPdu
Data type
USINT Interface
USINT Status
USINT
STRUCT of:
USINT Interface
USINT CablePair
USINT CableStatus
USINT
CableMinLength
USINT
CableMaxLength
USINTCableFailureL
ocation
Description
ACD Diagnostic Parameters
Description
Interface
Status (1=Active, 2=Success,
3=Failure, 4=Uninitialized)
Size of the Cable Test Result
STRUCT of:
2 Pair for 100BASE
4 Pair for 1000BASE
100BASE:{
{Interface, CablePair1,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair2,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
}
1000BASE:{
{Interface, CablePair1,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair2,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair3,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair4,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
}
