English
3. Lift up the wire cover (1) and turn it to
the front by 90 degrees to remove. Then,
remove the space cover (2).
RB37 Glass door models
• Open the fridge door, and slightly lift
up the left side of the wire cover (1) to
remove. Then, remove the space cover (2)
then the dongle PBA connector (3).
NOTE
Keep the space cover in a safe place. It is
necessary when you return the door to the
initial position (before reversing the door).
4. Remove the top frame cover (4) from the
bottom left then the top side. Then, pull
out to the front.
• For models that have the display panel
on the top of the fridge, locate the service
holes on the top frame cover (4).
- Insert a flat-head screwdriver into the
left hole and release the left side first
then the upper and lower locks of the
right side in this sequence. Then, slide
to the left to remove.
