Boffi RERX01 Montage- Und Serviceanleitung Seite 3

Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
RERX02
RERX12
Ø42,5mm
Ø 1"43/64
320mm
12" 19/32
4mm
5/32"
MAX
50mm
1" 31/32
3/8" GAS (EU)
9/16" (USA)
200mm
7" 7/8
Ø18mm
Ø 45/64"
235mm
9" 1/4
Ø50mm
Ø1" 31/32
355mm
13" 31/32
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
RERX04
RERX14
Ø42,5mm
Ø 1"43/64
180mm
7" 3/32
4mm
5/32"
MAX
50mm
1" 31/32
3/8" GAS (EU)
9/16" (USA)
-3-
122mm
4" 51/64
Ø18mm
Ø 45/64"
95mm
Ø50mm
3" 47/64
Ø1" 31/32
490mm
19" 19/64
