Caratteristiche di funzionamento
Pressione di servizio ideale: ..................... 3 bar
Pressione di servizio massimo: ............................ 5 bar
Temperatura acqua calda ideale: ........................ 60° C
Temperatura acqua calda massima: ................... 70° C
Attenzione:
Risciacquare bene le tubazioni prima del montaggio.
GB
Operating data
Ideal operating pressure: .......................... 3 bar
Max. operating pressure: ...................................... 5 bar
Ideal water temperature:...................................... 60° C
Max. water temperature:...................................... 70° C
Attention:
Before installation flush pipes thoroughly.
F
Caractéristiques de fonctionnement
Pression de service idéale: ...................... 3 bar
Pression de service max.: .................................... 5 bar
Température idéale de l'eau: ............................... 60° C
Température max. de l'eau: ................................. 70° C
Attention:
Rincer à fond la tuyauterie avant le montage.
D
Betriebsdaten:
Idealer Betriebsdruck: .............................. 3 bar
Max. Betriebsdruck: .............................................. 5 bar
Ideale Wassertemperatur: ................................... 60° C
Max. Wassertemperatur: ..................................... 70° C
Achtung:
Vor Montage die Leitungen gründlich durchspülen.
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
RERX01
RERX11
Ø42,5mm
Ø 1"43/64
180mm
7" 3/32
4mm
5/32"
MAX
50mm
1" 31/32
3/8" GAS (EU)
9/16" (USA)
-2-
130mm
5" 1/8
Ø18mm
Ø 45/64"
95mm
Ø50mm
3" 47/64
Ø1" 31/32
490mm
19" 19/64
