3. Layout & Connectors
3.2 Connectors
USB 3.2 (Gen1) B-Port:
StdB_SSTX +
StdB_SSTX -
D-
D+

4. Hardware Installation

Because there are large differences between PC's, we can give you only a general installation
guide. Please refer
1. Install the EX-1185HMVS-2 on a DIN rail using the supplied DIN rail kit or on a wall using the
wall mounting bracket.
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
VBus
GND
your computer's
Mounting on DIN Rail
Attention!
Never plug in with force
or in wrong direction.
reference manual
Holes for Wall Mounting
