2.B. CHECKING AND SETTING THE DIP SWITCHES
Check the configuration of the DIP SWITCHES (at the back of the UPS, see Figure
A) against the above table (according to the options installed, if any). The dip switch
configurations are illustrated in Figure B.
N.B. In the set-up illustrated in fig.d baud rate (speed of data transmission) is
programmed for a default value of 9600, if the personal computer in use is
not compatible with this value it may be altered in accordance with the table
below:
COM. 1
SW.1.3 SW 1.4
ON ON
OFF ON
ON OFF
OFF OFF
3. INSTALLATION – SYNTHESIS TWIN™
Plug the cable in the kit provided into one of the RS232 ports (at the back of the
UPS, see Figure C), depending on which other options are already installed, if any,
as shown in the table below:
Options installed
1
CONNECTIVITY
1
CONNECTIVITY
1
CONNECTIVITY +
1
CONNECTIVITY
1
CONNECTIVITY +
DISPLAY
(local or remote)
DISPLAY (remote) +
1
CONNECTIVITY
1
LIFE + CONNECTIVITY
1
CONNECTIVITY + JBUS
1
JBUS + CONNECTIVITY
1
Connectivity solution software
Hardware installation instructions – 10H92240P1 rev. 2 – 11/2000 – page 3
Baud rate SW.1.8
9600 ON
4800 OFF
2400 ON
1200 OFF
Plug into standard Plug into 2nd
RS232 RS232
1
CONNECTIVITY n.n.
n.n. CONNECTIVITY
1
CONNECTIVITY CONNECTIVITY
DISPLAY
1
CONNECTIVITY
(remote)
DISPLAY (remote) CONNECTIVITY
LIFE CONNECTIVITY
1
CONNECTIVITY JBUS
JBUS CONNECTIVITY
GB
COM. 2
SW. 2.1 Baud rate
ON 9600
ON 4800
OFF 2400
OFF 1200
Dip switch
configuration
Configuration 1
1
Configuration 2
1
Configuration 3
Configuration 4
1
Configuration 5
1
Configuration 6
Configuration 7
1
Configuration 8
