Assembly

Install a protective roof or wall if the explosion-protected electrical device is
installed outdoors.
If necessary, fit the Ex d enclosure onto the mounting rail.
Observe enclosure weight and, if necessary, use appropriate lifting appliances.
Secure the Ex d enclosure with four screws (assembly dimensions - see chapter
Technical data / Dimensional drawings).
Tighten all screws.
Danger due to not approved cable entries!
If a not approved cable entries are used, explosion protection can no
longer be guaranteed.
Use only cable entries approved for the required type of protection.
Danger due to open drillings or unused cable entries on the Ex d
enclosure!
The explosion protection can no longer be guaranteed if drillings or unused
cable entries of the Ex d enclosure are left open.
Close open drillings using stopping plugs certified (e.g. type 8294) and
unused conductor bushings using plugs certified (e.g. type 8174/8).
