Take a hose clamp and attach the loose end of the existing return hose to the water outlet of the solar mat.
2.6.

Installation instructions

Solar mat – pool outlet
These instructions assume that the pool and filtration system are already installed and that a pool hose is
attached to the pool's water inlet.
Solar mat – filter pump
1. Turn off the filter pump.
2. Block the water flow on both sides between the pool inlet and the pump outlet so that water does not
leak away through the hoses.
3. Disassemble the pool hose that runs from the filter pump to the pool inlet and lay it aside.
4. Depending on the filter pump and the desired location of the solar mat, you must select the input and
output of the solar mat.
5. Take a pool hose and connect it between the pump (where the return hose was previously connected)
and the water inlet of the solar mat, using hose clamps.
Solar mat – pool inlet
Take a hose clamp and attach the loose end of the existing return hose to the water outlet of the solar mat.

3. Operation

Once the solar panel has been assembled and the hoses are connected to the filter pump and pool return,
unblock the flow of water into the pool return hose and turn on the pump and filter system. Bubbles will shout out
of the return nozzle into the pool initially while air is pushed out of the solar panel. If this persists for longer than
2 or 3 minutes, check for any repair any leaks in the hoses or connections.
Note: be sure to place your pool cover on at night to prevent heat loss.
|
