How big is your pool?
▪
What size hose does it use between pool and filter pump (i.e. Ø 32 mm or Ø 38 mm)?
▪
What kind of hose connection does your pool use (i.e. threaded or unthreaded)?
▪
In which location will you position the pool for maximum sun exposure?
1.6.

Maintenance

The solar mat should not be exposed to cold weather. Prior to the first frost, or at the end your swim season,
the solar mat should be removed from its connections to the pool and stored in a frost-free location.
1.7.

Winterizing

Drain all the water from the solar panel by disconnecting the tubes. Store in a location protected from frost.
Reconnect the pool return tubes.
Do not allow standing water to remain inside the solar mat to freeze. Water expands as it freezes and can
rupture the solar coils on the heater. This will damage the solar mat and will void the warranty.
1.8.

Technical data

Vinyl collector, for pleasantly warm water. Finished solar collector for easy installation.
▪
Connection: Ø 32 mm
▪
Only for floor mounting
▪
Dimensions: 128 x 80 cm
▪
Flow rate max 3800 l/h
▪
Only suitable for cartridge filter systems

2. Installation

2.4.

Installation location

The solar mat must be placed lower than the water level of the pool. The solar mat should never be placed on
a roof or any other structure. The solar mat should never be placed more than 60 cm above the water level in
the pool.
Place the solar mat in a place where the most sunlight can be received and at least 3 meters away from the
pool.
Note: The solar mat must be placed between the filter and the water inlet of the pool, after the water has been
filtered. The solar mat MUST be placed behind the filter to prevent pressure build-up.
Important: If you use a saltwater system or in-line chlorinator, it must be placed after the solar mat to prevent
damage to the solar mat.
|
