5. Insert the backbox with the
attached aluminum frame into
the recess. Do not deform the
back box.
The wider side of the
aluminum frame needs to be
on the left side for horizontal
installation or on the bottom
side for vertical installation.
Page 9
6. Feed the mounting clamps /
doglegs through the openings
in the corners of the back
box and and use the included
screws and washer to press
the clamps tightly against the
back of the drywall.
Make sure the back box sits
straight and flush in the wall
recess.
