3 Luminaire Assembly

Visual color evaluations can also be performed with a luminaire set up
in a designated „color evaluation area".
Suspend the luminaire with snap hooks (and chains) over the work
area.
Place diffuser pins in brackets, rougher glass facing towards lamps.
Snap diffuser latch.
Connect several luminaires in a chain with cascade cables (refer to full
manual for detailed settings). Ready to plug in and turn on!
Setup recommendations
Please see SEA J361 for set-up of designated „color evaluation area".
Keep 30 cm distance to wall/ceiling or next luminaire.
Each luminaire needs adequate support, at least 50 kg.
Provide 1150 W per luminaire and follow local electrical regulations.
