• WARNING: No modification of this equipment is allowed.
• Do not store in damp conditions.
FR
• Do not use in an oxygen enriched environment.
• Do not use in an outdoor environment.
• No part of the medical device should be serviced while it is in use by the patient.
• The medical equipment requires 5 hours to warm from the minimum storage temperature before it is ready for its intended
use.
• The medical equipment requires 1 hour to cool from the maximum storage temperature before it is ready for its intended
DE
use.
• Intended for use in hospital, professional healthcare facility and home healthcare environments.
• The power unit is intended to be hung over the footboard of a bed.
• Wireless equipment such as mobile phones should be kept at least 1 foot or 0.3 metres away from the equipment.
• Do not connect the power unit or mattress to any other medical device or equipment.
• Risk of fire if incorrect fuse used.
ES
• The mattress and power unit should be cleaned between patient use, please refer to Care and Maintenance section for
all warnings and cautions.
• Not suitable for sterilisation.
• The mattress must be properly set up as directed.
• Check periodically to ensure patient support and comfort, adjusting the COMFORT CONTROL setting if desired.
• All hoses must be free of kinks, twists, properly connected and positioned so as not to cause an obstruction or injury.
IT
• In order for the alternating air pressure mattress/cushion to operate effectively, please avoid placing objects on the surface
that may obstruct the movement of air between the cells. For the same reason, please discourage people from sitting on
the edge or on the end of the mattress whilst it is in use.
• Do not use abrasive cleaners, phenol disinfectants, solvents or alcohol-based cleansers, e.g. Dettol, Phenicol,
Hibiscrub, Clearsol, Stericol, Hycoline, as these may destroy the cover materials (* see Care and Maintenance on
NL
page 9).
• The system is used as part of a pressure ulcer prevention and/or management program, not solely relied upon for this
purpose.
• It should be noted that the use of a cushion will increase the patient's seated height by approximately 5cm, and care should
be taken to ensure the patient's comfort and security regarding height of foot and arm rests.
• The above warnings, cautions and any safety considerations should be observed on a routine and regular basis, not only
EL
upon installation.

4. Installation Guidelines

4.1 Installing Mattresses

FI
NB. The power unit display default
language is English, but can be
changed to the language of your choice
(please see 'Setting/Changing Power
Unit Display Language' on page 7).
1. Remove any existing mattress from the
NO
bed frame (the QUATTRO mattresses
are intended to completely replace the
bed mattress).
2. Place the mattress on the bed frame.
Ensure the mattress hose exits at the foot end on the right hand side and the coloured cover is uppermost (Fig. 1).
DA
3. Secure the mattress to the bed frame using adjustable straps - pass straps around bed frame mattress platform
and secure with the buckles (Fig. 2), allowing for moving components on electric bed frames. This is important
as it stops the mattress becoming detached from the bed frame and causing possible injury to the patient. A strap
extension kit is available for use with divan beds (part number 11062).
SV
4
Q U A T T R O A C U T E & Q U A T T R O
®
Fig. 1
Power
unit
D I R E C T H E A L T H C A R E G R O U P. C O M
P L U S
®
Mattress (applied part)
Mattress air
supply hose
CPR
device
