Exploded View Parts List - 2 - JVC PD-42V31BJE Serviceanleitung

EXPLODED VIEW PARTS LIST - 2

Ref.No. Part No.
12 QQR0491-001
30 QQR1193-001
31 QLE0023-002
32 LC41684-001A
50 QYSBSFG4016M
51 LC21377-001B-0K
52 LC21377-002B-0K
53 LC11667-001B-0K
54 LC32433-001A
55 LC21425-001B-0K
56 QAS0154-001
3-6 (No.YA013)
Part Name
FERRITE CORE
CORE FILTER
PDP UNIT
DD SPEAKER ASS'Y
TAP SCREW
DUCT COVER (L)
DUCT COVER (R)
WFR BACK COVER
JVC PLATE
W SP HOLDER ASS'Y
SPEAKER
Description
(GRAY)(x2)
Inc.PWB in PDP UNIT
(x2)
4.0mm x 16mm(x26)
(x2)
Local
