GETTING TO KNOW YOUR CLEANER
A. Accessory Door*
B1. Hose Holder*
B2. Tube Holder*
C. Main Cleaner
D. Bag Door
E. Accessory Door Latch
F. On/Off Pedal
G. Cord Reel Pedal
H. Variable Power Control slider
I. Bag Check Indicator
J. Bag Door Latch
K. Hose Handle
L. suction Regulator
M. Hose
N. Telescopic Tube Adjuster*
O. Telescopic Tube*
P. Carpet and Floor nozzle(GP)**
GETTING TO KNOW YOUR CLEANER
Remove all components from the packaging.
1. Connect the hose to the cleaner main body. To release the hose: simply press the
two latches on the hose end and pull. [1]
2. Connect the hose handle to the tube upper end. [2]
3. Connect the tube lower end to nozzle**. [3]

USING YOUR CLEANER

1. Extract power cord and plug it into the power supply. Do not pull the cord beyond
the red marker. [4]
2. Adjust the telescopic tube to the desired height by moving the telescopic tube adjuster
and raise or lower the tube to the most comfortable cleaning position. [5]
Carpet & Floor Nozzle **. Press the floor type selector* on the nozzle [6] to select
3.
the ideal cleaning mode for the floor type.
P1. Carpet Nozzle (CA)**
P2. Hard Floor Nozzle (HF)**
Q. Floor type selector*
R. Bag
s. Pre-motor Filter
T. Exhaust Filter
U. Bag holder
V. Accessories:
V1. Crevice Tool*
V2. Dusting Brush*
V3. Furniture Nozzle*
W. Pet Hair Remover Mini Turbo Nozzle*
X. Allergy Remover Mini Turbo Nozzle*
Y. Grand Turbo Nozzle*
Z1. Parquet Nozzle*
Z2. Parquet Extra nozzle*
Hard Floor – Brushes are lowered to protect the floor.
Carpet – Brushes are raised for the deepest clean.
switch the cleaner on by pressing the On/Off pedal on the cleaner main body. [7]
4.
slide Variable power control to increase or decrease the power. [8]
5.
Adjust the suction regulator to the desired level. [9]
6.
7. switch off at the end of use by pressing the on/off Pedal. Unplug and press the cord
reel pedal to wind the power cord back into the cleaner. [10]
PARKING AND STORAGE SECTION
1. The tube can be parked on back or on the bottom of the cleaner for storage or
temporary storage while in use. [11]
2*. The hose, tube and nozzle can be in "Nano Pack" storage position when not in use: [12]
A. Retract the telescopic tube to its storage length.
B. Remove the nozzle from the end of the telescopic tube.
C. Remove the hose handle from the telescopic tube.
D. Lift the hose holder at the rear of the cleaner and wrap the flexible hose around
the product.
E. Park the hose handle on the product through the handle holder.
F. Assemble the nozzle into the parking slot underneath the product.
G. Assemble the telescopic tube into the remaining parking slot underneath the product.

CLEANER MAINTENANCE

Replacing the Dust Bag
If the bag check indicator is red please check and, if necessary, replace the bag.
1. Lift the bag door Latch to open the bag door, close the bag to avoid dust escaping
by pulling the tongue and remove the bag [13]. The full dust bag should be disposed
of correctly and carefully.
2. Fold a new bag as shown on the bag and fit by inserting the collar into the bag
holder. [14]
3. Close the Bag door.
REMEMBER: The bag check indicator may be red if an obstruction has occurred. In this
case refer to 'Removing a Blockage From the System'.
Cleaning the Filter:
To maintain optimum performance of your cleaner, please wash the pre-motor filter and
exhaust filter after each 5 bag changes.
Cleaning the pre-motor filter:
1. Lift the bag door latch to open the bag door.
2. To remove the pre-motor filter slide the pre-motor filter frame from the cleaner. [15]
3. Remove the filter from the holder. [15]
4. Wash it in hand warm water [16], and allow it to dry [17] thoroughly before replacing
to the cleaner [18].
2
*Certain Models Only **Nozzle design may vary according to models
