Set-up/Installation
3.5

Water Connection

3.5.1

Installation Layout Above the Water Level

Abbildung: Horizontaler Einbau
3.5.2

Installation Layout Below the Water Level

Figure: horizontal installation
3.5.3 Connecting the Electric Heat Exchanger to the Water Cycle of
a Filter System
Install the electric heat exchanger in the pressure line (to the basin) after pump and
filter.
The electric heat exchanger is integrated into the water cycle with PVC glued/
screwed connections.
The electric heat exchanger can be damaged.
When the heat exchanger is connected to the water cycle, please take care that
metal particles do not enter the electric heat exchanger.
36
Figure: horizontal installation
