Measurements

RBV 7010 COMPACT
Height
Width
Depth
Empty weight

RBV 7010 COMPACT technical diagram

Ø80 (SMOKE OUTLET)
The data shown below is provided as a guideline and is not binding, and may change based on what type of pellet is used. Ravelli reserves the right to make any changes
in order to improve product performance.
Use and maintenance manual RBV 7010 Compact
Unit of measurement
645 mm
785 mm
986 mm
120 kg
Ø48 (AIR INLET)
