MikroTik RB924i-2nD-BT5&BG77 Kurzanleitung

EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v6.47.8 or the latest stable version, to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
This series Quick Guide covers models: RB924i-2nD-BT5&BG77 (KNOT).
This is a wireless network device. You can find the product model name on the case label (ID).
Please visit the user manual page on
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Full technical specifications, brochures, and more info about products at
Configuration manual for software in your language with additional information can be found
If you need help with configuration, please seek a
This Wireless product is featuring Bluetooth® technology.
First steps:
Make sure your Internet service provider is allowing hardware change and will issue an automatic IP address;
Connect your ISP cable to the first Ethernet port;
Connect the device to the power source;
Open network connections on your computer and search for MikroTik wireless network - connect to it;
The configuration has to be done through the wireless network using a web browser or mobile app. Alternatively, you can use a WinBox configuration
://mt.lv/winbox ;
Open https://192.168.88.1
Click the Check for updates button and update your RouterOS software to the latest version, must have an active Internet connection;
In the Quick Set, WISP AP menu choose your country, to apply country regulation settings;
Set the antenna gain, depending on the antenna used;
Set up your wireless network password;
Set up your router password.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v6.47.8 или най-новата стабилна версия, за да се гарантира спазването на местните
наредби!
Крайните потребители са отговорни да спазват местните разпоредби, включително работа в рамките на законни честотни канали, изходна
мощност, изисквания за окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства MikroTik трябва да бъдат
инсталирани съгласно инструкциите.
Тази серия Кратко ръководство обхваща модели: RB924i-2nD-BT5&BG77 (KNOT).
Това е безжично мрежово устройство. Името на модела на продукта можете да намерите на етикета на калъфа (ID).
Моля, посетете страницата с ръководството за потребителя на
сканирайте QR кода с мобилния си телефон.
Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко
ръководство.
Пълни технически спецификации, брошури и повече информация за продуктите
Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на
Ако имате нужда от помощ при конфигурирането, моля, потърсете консултант
Този безжичен продукт се отличава с технологията Bluetooth®.
Първи стъпки:
https://mt.lv/um for the full up-to-date user manual. Or scan the QR code with your mobile phone.
consultant https://mikrotik.com/consultants
in your web browser to start configuration, user name: admin and there is no password by default;
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
https://mikrotik.com/products
at https://mt.lv/help
https://mt.lv/um за пълното актуално ръководство за потребителя. Или
на https://mikrotik.com/products
https://mikrotik.com/consultants
https://mt.lv/help-bg
tool https
