USING ONE SSW-1 SUBWOOFER WITH A SINGLE AMPLIFIER CHANNEL

Receiver/Processor
Subwoofer
Out

USING ONE SSW-1 SUBWOOFER WITH TWO AMPLIFIER CHANNELS

Subwoofer
Out
Receiver/Processor
Wire Length
Up to 30 ft.
Greater than 30 ft.

CarInG FOr YOur sPeaKers

• Wipe the cabinet with a clean, dry cloth to remove dust. A damp cloth may dull the cabinet's finish. Do not use
volatile liquids such as benzene, paint thinner or alcohol on the cabinet.
• Do not spray insecticide near the cabinet.
• To remove dust from the grille fabric, use a vacuum cleaner set to low suction.
• Do not wash the grille in water, as water may fade the grille's color or make it uneven.
• If the surface of the woofer cone becomes dusty, you can carefully sweep it clean with a soft, dry calligraphy brush
or paint brush. Do not use a damp cloth.
Amplifier
Line-Level Speaker-Level
Inputs Outputs
Line-Level Line-Level
Inputs Outputs
Channel 1
Channel 2
Amplifier
Recommended Size
14-gauge (minimum thickness)
12-gauge (minimum thickness)
6
SSW-1 Back Box
SSW-1 Back Box
