Thank you for buying a LSL product. Because of our passion for motorcycles all our products are designed to meet your needs as a motorcyclist. We wish you always a safe and pleasant ride with your new LSL product from Paaschburg

& Wunderlich GmbH.

CAUTION:

Important safety information. If you are not a trained mechanic, contact a specialist workshop to install the LSL product. Failure to comply with the installation instructions can cause damage to your vehicle and invalidate

your warranty claims. No liability is accepted for consequential damage. The manufacturer assumes no liability for damage due to improper installation of LSL products. Improper use of this product can impair driving safety.

Unauthorized reworking and / or changing of the LSL product can lead to failure of the function and is not permitted. Structural changes to the parts are prohibited and lead to the loss of liability and guarantee claims. It is not necessary

to make an entry in the vehicle papers or to carry documents with you. Please keep these instructions for future reference.

Scope of delivery LSL handlebar mirror RETRO.

• 1 pc. LSL RETRO mirror incl. adjustable stem

• 1 pc. installation adapter M10 x 1,25 right-hand thread

• 1 pc. installation adapter M10 x 1,25 left-hand thread

Assembly of the LSL mirror:

1. Make sure that your vehicle is positioned safely

Screw the correct adapter for your vehicle into the mirror arm (Fig. 1 and Fig. 2).

2. Now screw the mirror into the mirror mounts (A. Left or B. Right) on the handlebar (Fig. 3).

ATTENTION:

The mirror must be easy to screw into the mirror mounts on the handlebar.

Otherwise there is a risk of damaging the thread. You can find more adapters in our Webshop.

3. Adjust the mirror so that a good rear view is achieved.

4. Now lock the nut (A. Left or B. Right) on the mirror adapter against the mirror mount on the handlebar

(Fig. 4). To avoid damaging the thread, only tighten the nuts hand tight.

5. Make sure that the mirror or mirror arm does not interfere with the operation of other attachments or switches.

ATTENTION:

Before each ride, check whether parts or screws have loosened due to the vibrations and that the mirror setting is still correct.

Find suitable housings, turn signals, taillights, power resistors, electronic flasher relays, adapter cables and other accessories in our Webshop!

Fig. 1

Fig. 2

Before each ride: It is the duty and responsibility of the rider to regularly check and maintain the safety-related vehicle parts. Before starting your journey, check the correct adjustment and function of the LSL

products and the tightness of all screwed connections.

Warranty: Take the time to do a 100% professional job of installing the LSL products. Take into account all our installation and safety instructions.

A faulty, improper installation or handling of the product will void the warranty.

Maintenance/Care: Do not use aggressive detergents to care for the LSL products. The LSL products can be perfectly cleaned with a simple, lukewarm detergent solution. Contact with brake fluid, brake cleaner,

fuel, etc. should be avoided. Immediately pick up any unintentionally applied impurities with a soft cloth and clean the surface with detergent solution

Enviromental Information: This LSL product may not be disposed in the normal household rubbish at the end of its lifetime. The disposal can be done through the Paaschburg u. Wunderlich customer service

or a local return and waste collection institution.

Exclusion of liability and warranty regulation:

In the event of improper handling, installation or use of the device, warranty and guarantee claims may expire. Due to the non-verifiability of the correct application, Paaschburg und Wunderlich GmbH assumes no liability for direct or indirect damage or consequential damage resulting from the operation of the device.

This does not apply if the damage is based on intent or gross negligence on the part of Paaschburg & Wunderlich GmbH, or if the damage consists in injury to life, limb or health, or Paaschburg & Wunderlich GmbH has culpably violated an essential contractual obligation (cardinal obligation).

Paaschburg & Wunderlich GmbH, Am Alten Lokschuppen 10a, D-21509 Glinde

Tel.: +49 (0) 40 248 277-0; E-Mail:

sales@pwonline.de

132SRET2A_Rev00_2020-12

For assembly, first select the appropriate thread adapter.

Fig. 3

Mounting and safety instructions

LSL handlebar mirror „RETRO"

Fig. 4

Dimensions:

A: 100 mm

B: 100 mm
