Inputs
There is an input for operating voltage (15), an input for connection of a rechargeable battery
(LiIon, 14), an analogue input (16) and an optocoupler (17).
Observe the maximum input voltage of 2.8 V at the ADC and a maximum input voltage
of 32 V/DC at the optocoupler input and operating voltage!
Outputs
Each output has its own LED to display the current status. The first output (19) is already
connected to a relay.
Observe the connection data of the relay (5 A at 30V/DC or 8 A at 250 V/AC).
The second output (18) has a switching output of 32 V/DC and 300 mA. A relay can
be connected to this output (e.g. Conrad item no. 502892).
The relay must only be connected by a specialist. The devices must be powered down
before the casing lid is opened.
Aerial
The "GX107" has an installed aerial. If the reception is too bad or the "GX107" must be set up in a
place with bad reception conditions, you may connect an external aerial (Conrad item no. 199399).
A connection option for aerials with MMCX plug is provided in the casing (20). Check the reception
quality at the intended site of use with a mobile phone first.
SIM card
The SIM card is inserted in the holder on the front of the PCD (see section "preparation of the
SIM card").
GPS
An external GPS module can be connected to the 6-pin connection (13) on the PCB (Conrad item
no. 1629152). The GPS module is used for simple place determination of the "GX107" but can
also be used for object monitoring (see section "GPS Application and Settings").
