Modulation Section
Controls
Switches
LED
Utility Section
Controls
Sequencer/Arpeggiator Section
Number of step
Number of patterns
Memory storage
Controls
Switches
LEDs
Inputs and Outputs (TS 3.5 mm)
Inputs
Outputs
LFO rate: 0 to 10
Shape: pulse, triangular
LFO rate
Glide time: 0 to 10 (0 to 2 s)
VC mix: lo/mix 1 to hi/mix 2
32 steps maximum per pattern
64 patterns maximum
8 banks with 8 patterns each
Tempo/gate length
Hold/rest, reset/accent, arp/set end, pattern/bank, shift, page, play/stop,
record, keyboard mode, step mode, 13 note keyboard
8x octave/location
OSC cv: -5 to +5 V
OSC fm: -5 to +5 V
OSC mod: -5 to +5 V
VCF cutoff: -5 to +5 V
VCF resonance: -5 to +5 V
Mix 1: -5 to +5 V
Mix 2: -5 to +5 V
VC mix: -5 to +5 V
Multiple: -5 to +5 V
Mix cv: -5 to +5 V
Ext audio: -5 to +5 V
Tempo: -5 to +5 V
Play/stop: more than 3.2 V
Reset: more than 3.2 V
Hold: more than 3.2 V
Env gate: more than 3.2 V
VCA CV: -5 to +5 V
LFO rate: -5 to +5 V
Multiple: -5 to +5 V
Multiple: -5 to +5 V
OSC pulse: +/-5 V
OSC saw: +/-5 V
Env: 0 to 8 V
Noise: +/-5 V
LFO triangle: +/-5 V
LFO square: +/-5 V
VC mix: -5 to +5 V
Assign: 0/+5 V or +/-5 V
KB CV: -5 to +5 V
Gate: 0/+5 V
VCF: +/-5 V
