Instructions For The Installer; Installing The Hob In The Kitchen Unit - NEFF T63S46S0 Einbauanleitung

Please detach and keep

Instructions for the installer

All installation, regulation and adaptation to
other types of gas must be carried out by an
authorised installation technician,
respecting all applicable regulations,
standards and the country's electrical and
gas supply companies' specifications.
It is recommended that you call our
Technical Assistance Service for adaptation
to other types of gas. Before you begin, turn
off the appliance's electricity and gas supply.
Before connecting the appliance to the
supply, check that it is prepared for the type of
(Table I).
gas in question. Our hobs leave the
factory set for the gas type indicated on
characteristics plate.
This appliance must be installed in a place
with the proper level of ventilation. The gases
produced during combustion must be released
to the outside.
Check the size of the hob and the size of
the opening to be made on the kitchen unit.
The panelling on the work surface in the
immediate vicinity of the hob must be made of
non-flammable material. Both stratified coatings
and the adhesive used to fix them in place
must be heat resistant. Otherwise, they may
be damaged.
Electric wiring must not come into contact
.
with hot areas
The mains supply cable must be fixed to
the kitchen unit to prevent it from coming into
contact with hot parts on the oven or hob.
Appliances with electric components must
be earthed.
Handle the appliance with care throughout
the entire installation process. Avoid knocking
the appliance.
This appliance shall be installed in
accordance with the regulations in force
and only used in a well ventilated location.
Read the instructions before installing or
using this appliance.
SHOULD THE RELEVANT CONDITIONS
NOT BE PROPERLY SATISFIED, THE
INSTALLER, AND NOT THE
MANUFACTURER, SHALL HELD LIABLE.
Installing the hob in the
kitchen unit
The positioning of a hob in a kitchen unit
is Class 3 according to the standard for gas
appliances EN 30-1 . -1
Housing measurements
1- Minimum Distances (mm). Cut a hole of
the necessary size in the work surface, Fig. 1.
If no oven is installed under an electrical or
mixed (gas and electric) hob, place a
separator of non-flammable material e.g.
plywood or metal at a distance of 10 mm.
from the bottom of the hob to prevent access
to the lower part of the hob.
If no oven is installed under a gas hob, it is
suggested to place a separator of non-
flammable material e.g. plywood or metal at
a distance of 10 mm. from the bottom of the
hob to prevent access to the lower part of the
hob.
In the event that a drawer is located beneath
the appliance, please make sure that the
drawer contains no heat-sensitive or easily
combustible objects, such as spray cans or
shoe polish. Use a heat-resistant utility drawer
only.
For installation on top of an oven, check
the size of the oven as given in its assembly
manual.
If the cooking hob is to be installed above
an oven, check that the oven is fitted with
power ventilation, and check the dimensions
according
to the assembly manual.
All manuals and user guides at all-guides.com
Centre the hob in the hole on the work
surface.
2- The chipboard used to make the worktops
tends to swell quite quickly when it comes into
contact with moisture. Thus we recommend
treating the cut edges with a special glue, to
protect them from steam
that might drip down beneath the cooker
unit's work surface.
Depending on the model, the clips and the
watertight seal (lower edge of the cooking hob)
may already be fitted; if this is the case, do not
remove them under any circumstance.
The seal ensures that the entire work
surface will be watertight, and prevents water
seepage.
the If this item has not been fitted in the factory,
remove the pan supports and the gas burner
covers and diffusers from your cooking hob,
and turn it upside down. Now fit
seal supplied with the appliance onto the
lower edge of the cooking
remove
the model Fig 2a/2b
the attached accessories bag and
them into the lower points designed for
purpose, depending on the model Fig. 3d.,
place them in the holes provided for this purpose
according to the clip model Fig. 3a or Fig. 3b.
At the same time, press down on the hob
edges to ensure that the cooking hob is
supported all the way round Fig. 4.
If your cooking hob model comes with the
clip type which corresponds to Fig. 3d., once
the hob is fitted you should turn the clip and
tighten the screw as shown in Fig. 3e.
3- For disassembly, unscrew the clip and
proceed in the reverse manner.
• If your clip is type Fig. 3a you should push
from below upwards.
• If your clip is type Fig. 3b you should use
a screwdriver to lever it upwards Fig. 3c.
4- The end of the input collector on gas
1 /
hobs comes with a "
2
Fig. 5. This caters for:
threaded L-tube,
•Rigid connection.
•Connection to a flexible metal tube
(L min.1m - max.3m). If this method is used,
avoid both contact between this tube and moving
parts on the housing (e.g. drawers) and passing
the tube through spaces liable to get blocked.
In either of the cases, do not move or twist the
L-tube from its factory-set position.
To use this appliance in France, it is necessary
to remove the L-tube mounted in the factory
and assemble the one supplied in the accessory
bag. Fig. 5a. Do not forget to insert the seal.
If, for some reason, the L-tube should be twisted,
it is necessary to make sure that this area is
properly sealed. Make sure that all connections
performed are free of leakage.
The manufacturer does not accept any
liability for leakage on connections performed
by the installer or if the L-tube is moved or
twisted.
5- Check the voltage and total power on
the characteristics plate. The appliance must
be EARTHED.
Make sure that connection has been
performed in accordance with legal regulations
in force for the country in question. Comply
fully with the conditions laid down by the local
electricity company.
In order to meet normal safety standards,
the installer must supply an all-pole circuit
breaker with a contact aperture of at least 3
mm. This is not necessary when connection is
made via a socket, so long as this is accessible
to the user.
Appliances equipped with plugs should
only be connected to sockets which are duly
earthed.
The appliance is type "Y". This means that
the input supply cable cannot be changed by
the user. Only the brand's service technicians
are qualified to replace this cable. Use the right
cable type and section.
Do not tamper inside the appliance. If
necessary, call our Service Centre.
Hobs with control knobs are supplied with
a plugged or unplugged power cable.
TYPES OF CABLE
Cooking hob:
All gas
Electric plate 1 kW
or any condensation
Electric plate 1.5 kW
6-In order to complete the installation
process, you must place the diffusers and the
tops of the burners on their corresponding
burners. Also you must place the metal grids
correctly on their supporting elements.
Changing the type of gas
the adhesive
All installation, regulation and adaptation to
other types of gas must be carried out by an
hob, depending on
authorised installation technician,
the clips
from
respecting all applicable regulations,
screw
standards and the country's electrical and
this
or
gas supply companies' specifications.
It is recommended that you call our
Technical Assistance Service for adaptation
to other types of gas. Before you begin, turn
off the appliance's electricity and gas supply.
*Before connecting the appliance to the
supply, check that it is prepared for the type of
gas in question. Our hobs leave the factory set
for the gas type indicated on the characteristics
plate.
Depending on the regulations in force in
your country, this hob may be adapted to work
with other types of gas (see characteristics
plate). To adapt the gas type, proceed as
follows:
(20,955 mm)
A ) Changing the injectors on the burners
(Table II)
1 -Remove the grates, covers and burner
core.
2 -Change the injectors using a 7-mm
socket wrench and be sure to tighten them
down properly so that they are fully air-tight.
Fig. 7.
It is not necessary to adjust the primary air
on these burners.
B ) Adjusting reduced consumption on
the burner valves.
1 - Set the valves to minimum.
2 - Remove the control knobs from the
valve shafts. Fig. 8.
3 -
Do not remove the disc seal
• If your hob only has inner seals made of soft
plastic, dismount these by levering around
them with a screwdriver to access the
adjustment screw.
4 -Adjusting the by pass screw.
•For Propane and Butane Gas: the screw must
be tightened down fully.
•For Natural Gas: turn the screw in an anti-
clockwise direction until the correct release of
gas is reached: when the burner is changed
from the maximum to minimum settings, the
flame does not go out or backfire .
5 - Re-assembling the anti-liquid seals. All
the seals must be in place in order to ensure
the water-tightness of the electricity system
against the spillage of liquids on the hob.
6 - Re-assemble the control knobs.
Never dismount the valve shaft (Fig. 10):
in the event of damage, change the entire valve.
C) Put the label which indicates the type
of gas the appliance has been adapted to
near the characteristics plate.
