Captain Flint Wall
CABLAGGIO - WIRING
<HAR> H05/07 RN-F
7<Ø<12 mm cable
3G1,5mm / 5G1,5mm
FASCICOLO Captain Flint Outdoor (MV 1101536 Rev01-21) per stampa 124x175mm_scala83%.indd 17
FASCICOLO Captain Flint Outdoor (MV 1101536 Rev01-21) per stampa 124x175mm_scala83%.indd 17
5
6
CONNECTOR INCLUDED (ON-OFF)
immagine indicativa - image representative
4mm max
CONNECTOR INCLUDED (DALI / 1...10V)
immagine indicativa - image representative
4mm max
4
1NC
5N
2NC
4
3L
1D(+)
5N
2D(−)
4
3L
OK
