Technical specifications
Supply voltage :
Type of action, disconnect and appliance:
Type of output:
Section of wires at terminals:
Insulation type:
Protection category:
Pollution:
Operating temperature limits:
Storage temperature limits:
Battery life:
Time remaining from when "Battery Low" symbol:
Addjustment temperature range:
Setting temperature resolution:
Display temperature resolution:
Thermal gradient:
Differential operation:
Temperature refresh:
Reference standards for EC mark:
(Direttives 89/336/CEE - 73/23/CEE)
ENGLISH
2 x 1.5V alkaline battery - type LR03 (AAA)
1.5 V 1050 mA/h
1 / B / U / Electronic
relay with single-pole changeover contact, voltage-free,
NC / COM / NO - 8(2)A / 250 V~
min. 0,75 mm
2
÷ max. 1.5 mm
2
Class II
IP 30 / surface-mounted model
normal
-5 °C ÷ + 55 °C
-10 °C ÷ +65 °C
12 months approx.
1 month approx.
+5 °C to +39 °C
0.5 °
0.1 °C
max 1 °K/15 min.
T variable from 0.2 °C to 2 °C
once every 60 seconds
LVD
EN60730-1
EN60730-2-7 EN60730-2-9
EMC
EN55014-1
EN55014-2
Performance
• 3 adjustable temperature levels + antifreeze
5 °C fixed
• operating mode: Winter
• manual mode operation (temporary or
permanent)
• burner (air conditioner) stop (max. 3 hours) for
room-cleaning
• total thermic regulation switch off
• general reset to clear memory
• day, hour and minutes change (e.g. daylight
saving time)
• smart operation with maximum 2 hours early
switch-on
• time or room temperature display
• telephone programmer connection for remote
control
• 4 fixed programs
• one completely free program (P 5)
(minimum programmable time:
• a "count-down" program (P 6) that can be used
to suspend the program currently selected for a
set interval (max. = 999 h.)
• display of daily and total operation hours
• error indication: temperature out of range,
EN61000-3-3
probe failure, system trouble
(heating)
Summer
(air conditioning)
1
/
hour)
2
P - 5
