TECHNICAL DATA

Standards
Protocols
Transfer rate
Transfer procedure
Modulation
Frequency Band
Range
Security
Platform Support
LED Indicators
HomePlug connection
Computer interface
Power consumption
Power supply
Temperature
Environment
System requirements
(for Configuration
Utility)
External Connectors
Dimension
Weight
PowerLan 100 Ethernet Adaptor
10 Base-T Ethernet, IEEE 802.3
10 Mbps Auto MDI / MDIx Support
14 Mbps HomePlug 1.0 compatible
CSMA/CA MAC control
14 Mbps
Asynchronous
OFDM, DQPSK, DBPSK, ROBO
Carrier Modulation Support
4.3 Mhz to 20.9 Mhz band
Up to 200 meters
56 bit DES
OS Independent with TCP/IP protocol installed
and with Ethernet port
1x Power LED
1x Powerline Link Status LED
1x Ethernet Link/Activity Status LED
Standard power plug
RJ45
5.8W
Integrated 230V AC Supply via Power Socket
Storage: -25°C -70°C
Operation: suitable for room temperature, 27°C
Suitable for room temperature, 27°C, 10-90%
humidity (non-condensing)
Ethernet interface
Windows 98SE, Windows Me,
Windows 2000, Windows XP
1 x Electrical Power Socket
1 x RJ45 for 10Base-T Ethernet ( AutoMDI/MDI-
X)
Plastic housing
92mm x 66mm x 45mm(height x width x depth)
Approx 180g
