Topcom PowerLan 100
The Advanced dialog screen allows you to set up a network
password remotely on other PowerLan devices through the
powerline.
Type your private network password into the Network Password
text box.
The other devices on the network with HomePlug capabilities will
have a Security ID/Device Password printed on the device
itself. Find the passwords for all devices you want to manage and
type them one by one into the Device Password text box and
Click on the Add button. This will add the passwords to Remote
Passwords text list box and set them to the currently defined
Network Password.
Important Note:
The device must be present on the powerline in order for the
password to be confirmed and added to the Remote Passwords
list.
The Status indicates whether each device is successfully set to
the Network Password. An "OK" indicates success while "Fail"
indicates a failure.
Click on the Set All button to apply your private network
password to all devices that are listed in the Remote Passwords
text list box and to your local device connected to the computer
where the utility is running as well.
Select a password and Hit the Remove button to remove it from
the list.
Topcom PowerLan 100 13
